圓錐滾子軸承-上海嘉盛軸承有限公司

基本尺寸			基本額定載荷		軸承類型	軸承圖片	型號
			dynamic	static	Type	Images	Model
d[mm]	D[mm]	B[mm]	C[kN]	C₀[kN]
509.948	654.924	377	4950000	17100000	圓錐滾子軸承		STF509KVS6551E
482.6	615.95	330.2	4200000	13500000	圓錐滾子軸承		STF482KVS6151E
457.2	596.9	276.225	3400000	9850000	圓錐滾子軸承		STF457KVS5951E
450	595	368	4550000	14100000	圓錐滾子軸承		STF450KVS5901E
430	575	380	4650000	14200000	圓錐滾子軸承		STF430KVS5751E
406.4	546.1	288.925	3400000	9450000	圓錐滾子軸承		STF406KVS5451E
355.6	482.6	265.112	2650000	7350000	圓錐滾子軸承		STF355KVS4851E
343.052	457.098	254	2430000	6700000	圓錐滾子軸承		STF343KVS4551E
304.902	412.648	266.7	2320000	6350000	圓錐滾子軸承		STF304KVS4152E
304.8	419.1	269.875	2450000	6550000	圓錐滾子軸承		STF304KVS4151E
304.648	438.048	280.99	2640000	6750000	圓錐滾子軸承		STF304KVS4351E
279.4	393.7	269.875	2360000	6050000	圓錐滾子軸承		STF279KVS3951E
276.225	393.7	269.875	2360000	6050000	圓錐滾子軸承		STF276KVS3951E
266.7	355.6	230.188	1640000	4500000	圓錐滾子軸承		STF266KVS3551E
254	358.775	269.875	2150000	5650000	圓錐滾子軸承		STF254KVS3551E
244.475	327.025	193.68	1240000	3300000	圓錐滾子軸承		STF244KVS3251E
241.478	349.148	228.6	1730000	4150000	圓錐滾子軸承		STF241KVS3451E
220	340	303.5	2490000	5950000	圓錐滾子軸承		STF220KVS3401E
170	240	175	870000	2000000	圓錐滾子軸承		STF170KVS2401E
939.8	1333.5	952.5	26900000	92000000	圓錐滾子軸承		939KV1351
840	1170	840	22200000	76000000	圓錐滾子軸承		840KV1151
762	1066.8	723.9	18000000	59500000	圓錐滾子軸承		762KV1051
749.3	990.6	605	13000000	47000000	圓錐滾子軸承		749KV9951
711.2	914.4	317.5	5500000	19300000	圓錐滾子軸承		711KV9151
685.8	876.3	352.425	6350000	22200000	圓錐滾子軸承		685KV8751
635	900	660	13300000	43500000	圓錐滾子軸承		635KV9001
609.6	787.4	361.95	5750000	18700000	圓錐滾子軸承		609KV7851A
571.5	812.8	593.725	11700000	37000000	圓錐滾子軸承		571KV8151
558.8	736.6	409.575	6050000	19400000	圓錐滾子軸承		558KV7352
509.948	654.924	377	4700000	16100000	圓錐滾子軸承		509KV6551
